Compact And Durable 4G LTE WiFi Router With 160mm L X110mm W X25mm H Size
Technical Parameter
| Module | Parameters |
| User interface | 4 10/100/1000M RJ45 port
1*POTS 2.4GWiFi/5GWiFi |
| PON | EPON&GPON mode adaptive Interface Type:SC-UPC/SC-APC Security:ONU authentication mechanism Network coverage radius:20KM |
| GPON:upstream 1.25Gbps/downstream 2.5Gbps Optical receive sensitivity:-7dBm~-28dBm Continuous light power: 0.5dBm~+5dBm |
| EPON:upstream 1.25Gbps/downstream 125Gbps Optical receive sensitivity:-7dBm~-27dBm Continuous light power: 0dBm~4dBm |
| Ethernet | 4*10/100/1000Mauto-negotiation Full/half duplex mode RJ45 connector Auto MDI/MDI-X 100m distance |
| Size | 160mm(L)X110mm(W)X25mm(H) |
| Environment | Operating temperature:0°C~60°C Operatinghumidity:10%~85% non-condensing Storage temperature:-40°C~80°C Storage humidity:5%~95% non-condensing |
| Power supply | 12V1.5A DC power interface size:2.1mm/5.5mm |
| Power Consumption | <12W |
| POTS Port | 1*RJ11 Max 1km distance Balanced Ring,55V RMS |
| Man | WEBTELNET/TRO69/OMCI/OAM |
WIFI Features(2.4G/5G)
- Wi-Fi Specification IEEE 802.11n compliant,2.4 GHz/5G
- Full IEEE 802.11b/g/ac legacy compatibility with enhanced performance
- Two-stream spatial multiplexing up to 866 Mbps PHY data rates
- Support multi-SSID (Maximum 4 SSID)Support automatic channel selection
- Support hide SSID
- Support wireless security of 64/128 bit WEP802.1x,WPA and WPA2
Ordering Information
| Product Model | Descriptions |
| X410DW | 4*10/100/1000M Ethernetinterface(RJ45) 1 EPON & GPON adaptive interface
2.4G WIFI&5G WIFI
1*POTS |
